1✉ Department of Plant Protection, Faculty of Agriculture, Al-Baath University, P.O. Box 77, Al- Sham St., Homs, Syria.
2Entomology Research Laboratory, University of Vermont, 661 Spear Street, Burlington, Vermont, 05405-0105, USA.
3CBGP, INRAE, CIRAD, IRD, Montpellier SupAgro, Univ Montpellier, Montpellier, France.
2022 - Volume: 62 Issue: 1 pages: 58-67https://doi.org/10.24349/6gnq-wcbz
With about of 2400 species, the Tenuipalpidae and Tetranychidae are considered the largest and most diversified groups of the superfamily Tetranychoidea. These two families comprise several species of major economic importance, which occur throughout the world and often cause severe injury to agricultural crops and ornamentals (Krantz and Walter, 2009; Castro et al., 2021; Migeon and Dorkeld, 2021). Until 2015, data on Tetranychidae and Tenuipalpidae biodiversity were scarce in Syria and only six species were recorded: two tenuipalpids and four tetranychids (El-Hariri, 1968). Recently, these records increased to 13 and 23 species of Tenuipalpidae and Tetranychidae, respectively, within a six year period (Zriki et al., 2015; Barbar, 2016; Zeity, 2017; Barbar, 2018; Zeity and Negm, 2019; Zeity and Srinivasa, 2019; Barbar and Auger, 2020; Ebraheem et al., 2022).
The research herein provides new data on phytophagous diversity by identifying flat mites and spider mites species occurring on randomly sampled vegetation in Latakia governorate in 2021. In this manuscript a new species of Bryobia is described and illustrated and new records of Tenuipalpidae and Tetranychidae are reported.
Tetranychoid mites were randomly taken in Latakia governorate, Syria, on 5 and 20 April 2021. They were collected from leaves of wild vegetation at three different sites: i) in a public garden located at the center of Latakia city (35°51′65″ N, 35°78′18″ E); ii) in Alhafah (35°60′21″ N, 36°11′50″ E); and iii) in Slanfeh (35°60′70″ N, 36°22′17″ E). Mites were removed from leaves using the ''dipping-checking-washing-filtering'' method (Boller, 1984). Collected mites were cleared in lactic acid for 48 hrs, mounted on slides in Hoyer's medium, and dried in an oven at 40 °C for three days.
The specimens were examined using an Olympus® CH20 microscope at 400 and 1000x magnification. Measurements were taken using the scale of a reticle installed on the eyepiece lens. Mite body parts were documented using a mobile phone camera (13 megapixels) fixed on the eyepiece lens and images were transferred to a professional quality vector graphics (software Inkscape ® 0.92) which was installed on a computer for actual drawing.
All measurements are given in micrometers (µm) and the setal nomenclature used in the description follows Lindquist (1985). The holotype measurements are followed by measurements of the range of paratypes in parentheses. Body length represents the distance between the base of setae v1 to the end of idiosoma and body width represents the widest transverse part of the hysterosoma. Distance between sc2 setae members and between v2 and h1 setae are also given (Saito et al., 1999). The distance between two setae was measured as the distance from the center of one setal base to the other. Legs were measured from coxae to the distal margin of tarsi (excluding claws and empodia). Leg setal counts are given in the order: coxa-trochanter-femur-genu-tibia-tarsus. Numbers of setae refer to tactile setae, solenidia are given in parentheses and alternative counts are given in brackets.
Three females were collected on Juniperus oxycedrus L., Slanfeh (35°60′70″ N, 36°22′17″ E), Latakia governorate, Syria, 20 April 2021. This is the first record of this species from Syria. It has been mainly collected on several species of Juniperus sp. and found in Georgia, Iran, Turkey and Ukraine (Castro et al., 2021).
Four females were collected on Crataegus azarolus L., Alhafah (35°60′21″ N, 36°11′50″ E), Latakia governorate, Syria, 20 April 2021. This is the second record of this species from Syria (Barbar, 2018). It has been mainly collected on Rosaceae and particularly found in Mediterranean countries (Castro et al., 2021).
Twenty-one females of this species were collected: one female on J. oxycedrus, one on Pinus halepensis Mill., three on Centauria calcitrapa L., six on Cedrus libani (A.Rich.), six on Primula vulgaris Huds., and four on Lamium striatum Sibth. & Sm., Slanfeh (35°60′70″ N, 36°22′17″ E), Latakia governorate, Syria, 20 April 2021. This is the first record of this species from Syria. It has been mainly collected on Pinaceae and particularly found in Europe and Asia (Castro et al., 2021). The collecting of C. lineola on unusual host plants in this study (e.g. C. calcitrapa) could be due to the growing of these plants under several tree species belonging to Pinaceae or other families, which constitute a possible source of this mite in particular at the beginning of spring when the samples were taken.
One female of this species was collected on J. oxycedrus, Slanfeh (35°60′70″ N, 36°22′17″ E), Latakia governorate, Syria, 20 April 2021. This is the first record of this species from Syria. It has been collected on Juniperus sp. and found in Armenia, China, Georgia, Greece, Hungary and Ukraine (Castro et al., 2021).
One female of this species was collected on C. calcitrapa, Slanfeh (35°60′70″ N, 36°22′17″ E), Latakia governorate, Syria, 20 April 2021. This species has been collected from Bituminaria bituminosa (L.) (Zeity and Srinivasa, 2019) and from soil litter in Syria (Barbar and Auger, 2020).
Two females were collected on C. calcitrapa, Slanfeh (35°60′70″ N, 36°22′17″ E), Latakia governorate, Syria, 20 April 2021. This species has been collected from Trifolium sp. and Taraxacum campylodes in Syria (Zriki et al., 2015).
Type material — Holotype (female) and three female paratypes from Calicotome villosa (Poir.) Link. (Leguminosae), Alhafah (35°60′21″ N, 36°11′50″ E), Latakia governorate, Syria, 20 April 2021, coll. Z. Barbar. Material has been deposited in the Arthropod Collection of the Department of Plant Protection, Faculty of Agriculture, Albaath University, Homs, Syria.
Diagnosis — This species belongs to the berlesei-group due to prodosomal lobes well developed, no duplex setae on tarsus IV and femoral interior dorsal row with four long setae (Eyndhoven and Vacante, 1985). Prodorsum with two large oval-shaped lateral depressions. Opisthosoma bearing 6 large oval-shaped depressions with elongate ribbon-shaped pattern and one triangularly rounded depression caudally. Dorsal body setae serrate spatulate, except f2 and h1 elongate, acute distally, f2 and h1 longest. Dorsocentral setae of each row with members close to each other. Femora and genua II-IV with some flattened setae.
Female description — 625 (605–616 µm) long including lobes (base of setae v1 ) and 391 (381–383) wide, gnathosoma 95 (75–110) long. Distances between sc2–sc2 325 (294–320) and between v2–h1 614 (598–600).
Dorsum – Prodorsum with four pairs of setae, with rounded, oval and elongate reticulation medially surrounded by granulation, with two large oval-shaped lateral depressions containing irregular folds forming oval patterns (Figures 1 and 2A); well-developed anterior prodorsal lobes, inner lobes conical measuring 53 (50–52) high (excluding setae), separated by wide V-shaped incision 31 (15–21) in depth (measured from the bottom of the incision between the inner lobes to their tip, excluding setae) (Figure 2A); outer propodosomal lobes subtriangular to conical 35 (32–33) high (excluding setae); tip of setae v2 slightly surpasses setae v1 insertions; setae v1 shorter than setae v2. Distance between members of first (v1) and second (v2) pair of propodosomal setae insertions 28 (28) and 103 (98), respectively. Opisthosoma with six large oval-shaped depressions containing elongate ribbon-shaped reticulations (3 pairs posterolateral to setae c1, d1 and e1 and one triangularly rounded caudally; Figure 1) and with large mostly transverse folds medially. Dorsal body setae serrate spatulate, except e3 and f1 subspatulate, f2 and h1 elongate, narrower, acute distally; setae v1 the shortest, f2 and h1 the longest. Among dorsocentral setae, c1 larger and less spatulate than setae d1 and e1 (Figure 1 and 2B, D and E) except in one specimen (Figure 2C). All dorsal setae inserted on obvious tubercles (those of f1, f2 and h1 the biggest). Measurements of dorsal setae: v1 27 (25–26); v2 38 (32–34); sc1 50 (44–50); sc2 42 (40–46); c1 42 (35–40); c2 40 (34–44); c3 36 (34); d1 34 (27–33); d2 46 (37–42); d3 39 (37–41); e1 33 (25–39); e2 44 (44–45); e3 45 (45–52); f1 48 (51); f2 60 (67–69); h1 71 (64–72); dorsal setae width v1 9 (8–10); v2 14 (13–14); sc1 11 (15–18); sc2 11 (15–16), c1 15 (21–23), c2 15 (14–18) , c3 14 (17–20), d1 13 (17–19), d2 13 (14–19), d3 14 (16), e1 15 (15–17), e2 12 (17–18), e3 13 (11–16), f1 12 (10–16) , f2 10 (7–12) and h1 9 (8–11).
Distances between setae: c1–c1 40 (40–45), d1–d1 40 (33–42), e1–e1 22 (22–30), f1–f1 155 (135–140), f2–f2 76 (75), h1–h1 15 (18–20), c1–d1 105 (98–104), d1–e1 90 (85–92).
Gnathosoma – Stylophore slightly notched anteriorly, 92 (90–101) long and 73 (74–78) wide. Tibial claw of palpus bidentate (Figure 3A). Palptarsus slightly longer (excluding setae) 18 (19–18) than tibial claw 15 (15–16), with three tactile setae, three eupathidia and one solenidion, the shortest (Figure 3A). Tip of tibial claw reaches insertion of proximal tarsal tactile seta ''a''. Peritreme anastomosed distally, elongate, 33 (27–32) long 7 (9–8) wide (Figure 3B).
Venter – Area immediately anterior to genital flap irregularly longitudinal. Three pairs of pseudanal setae (ps1-3) and two pairs of ventrocaudal setae (h2-3) present. Sacculus of spermatheca elongate 23 (20) long 8 (10) wide (Figure 3C).
Legs – (Figures 4 and 5). Internal dorsal row of femur I with 4 long serrate setae 53 (50–55) and one normal seta 28 (27–30). Leg I 536 (528–541) long, leg II 340 (322–333), leg III 333 (315–322), leg IV 400 (396–430). Length of segments of leg I as follows: trochanter 45 (42–50), femur 156 (142–160), genu 75 (67–75), tibia 108 (104–112), tarsus 86 (83–86). Femora and genua II-IV with some flattened setae. Leg setal counts as follows (Figure 4):
I: 2 – 1 – 12 – 6 – 13 + (1) – 18 + (4) + 2 duplexes
II: 1 – 1 – 10 – 5 – 9 – 16 + (1) + 1 duplex
III: 1 − 1 − 7 – 6 – 9 –13 + 1 duplex
IV: 1 – 1 – 6 – 5 – 9 − 14 + (1)
True claws uncinate. Claw and empodium I with one and three pairs of tenent hairs, respectively (Figure 5A). Claws II-IV each with three pairs of tenent hairs and empodia II-IV consist of two rows of tenent hairs (Figure 5B). Tarsus III associated tactile seta 21 (20–20) and solenidion 15 (15–20) forming duplex (Figure 5C); on tarsus IV solenidion 7 (8–10) shorter and proximal, well-separated (7) from tactile seta 22 (20–20) (Figure 5D). Coxisternal setae 1b and 1c smooth: 1b, 54 (53–60), longer than setae 1c 33 (33–40).
Etymology — The name of the new species ''hadizeni'' is composed of the first names of Hadi and Zen, sons of the first author, to whom the new species is dedicated.
Remarks — Bryobia (L.) hadizeni sp. nov. is very close to B. (L.) cooremani Eyndhoven and Vacante (1985), but this new species differs from it by (1) having obvious large dimples on idiosoma vs. absent in B. (L.) cooremani (2) having setae f2 elongate, subspatulate and longer (60–69), and h1 elongate, narrow, acute distally and longer (64–72) vs. elongate spatulate: f2 30–50, h1 30–47 in B. (L.) cooremani; (3) having longer seta c1 35–42 vs. 22–33 in B. (L.) cooremani; (4) having distances between c1–c1 40–45, d1–d1 33–42, e1–e1 22–30 shorter vs. c1–c1 72–90, d1–d1 55–70, e1–e1 33–50 in B. (L.) cooremani; (5) having longer setae in the internal femoral upper row of leg I: 50–55 long vs. about 40 in B. (L.) cooremani; (6) having some flattened setae on femora and genua II-IV vs. all legs with normal setae in B. (L.) cooremani. Bryobia (L.) hadizeni sp. nov. is easily separated from B. (L.) pelerentsi Eyndhoven and Vacante (1985) previously recorded from C. villosa by: (1) the lack of obvious large dimples on idiosoma in B. (L.) pelerentsi which also have a narrower body (300–320 µm); (2) differences in the shape of several dorsal setae: c1 shell-like vs. spatulate elongate, f1 and f2 spatulate wide vs. elongate subspatulate and h1 elongate spatulate vs. elongate narrow and acute distally in B. (L.) pelerentsi and B. (L.) hadizeni sp. nov., respectively; (3) a different ratio between palptarsus and thumbclaw about 1.5 in B. (L.) pelerentsi vs. subequal in length in B. (L.) hadizeni sp. nov.; (4) having three pairs of tenent hairs on empodium I vs. two pairs in B. (L.) pelerentsi.
Six females were recorded from Hordeum sp., in a public garden located at the center of Latakia city (35°51′65″ N, 35°78′18″ E). This is the first record of this species from Syria. It is widely found on several species of Poaceae in Palearctic region (Migeon and Dorkeld, 2021).
Authors would like to thank Owen Seeman and Tea Arabuli for their valuable suggestions. Thanks also due to Maharn Zeity and M. Fawaz Azmeh for their valuable help in the identification of some host plants.
